Products Center
Golf Cart
Product features
Main application areas
Fast charging: freely charge at maximum 1C and 2C high rate
High and low temperature resistance: achieve normal work from -20℃ to 60℃
Maintenance-free: no need maintanance of performance released at low temperature when adopted thermal management; no need manual maintenance with fully enclosed structure
Improved safety: the battery management system achieves real-time monitoring and adjustment
Efficient energy saving: up to 95% energy conversion rate with fast charging(1-2 hours of charging can meet 2-4 hours of operational use)
Sightseeing vehicle, golf cart matching batteries
Model | Nominal Voltage(V) | Nominal Capacity (Ah) | Nominal Energy (Wh) | Operating Voltage (V) | Dimensions (mm) | Weight(kg) | Download |
---|---|---|---|---|---|---|---|
GP48-80 | 48V | 82Ah | 3936 | 37.5-54.75 | L482.6*W353*H263 | 45 | |
GP48-105 | 48V | 105Ah | 5040 | 37.5-54.75 | L527.6*W310*H263 | 45 | |
GP48-150 | 48V | 150Ah | 7200 | 37.5-54.75 | L540*W360*H264 | 65 | |
GP48-200 | 48V | 200Ah | 9600 | 37.5-54.75 | L680*W420*H264 | 85 | |
GP48-210 | 48V | 210Ah | 10080 | 37.5-54.75 | L606.6*W454*H250 | 88.5 | |
GP51-105 | 51.2V | 105Ah | 5376 | 40-58.4 | L500*W343*H268 | 48 | |
GP57-150 | 57.6V | 150Ah | 8640 | 45-65.7 | L680*W420*H242 | 78 | |
GP76-150 | 76.8V | 150Ah | 11520 | 60-87.6 | L680*W420*H275 | 120 | |
GP76-200 | 76.8V | 200Ah | 15360 | 60-87.6 | L1100*W290*H312 | 138 |
