Commercial Starting & Parking AC EFB Series
The robust, cost-effective upgrade for commercial fleets requiring enhanced durability, offering improved charge acceptance and thermal stability for both engine starting and extended parking air conditioning use.
Key Features
-
Optimized for Truck Off-Engine AC Use
Great deep cycle & strong startup performance.
-
Long Service Life
Thick special-alloy cast grids extend cycle life.
-
Premium PE-Glass Mat Separator
Low-resistance PE-glass mat separator reduces active material shedding.
-
Vibration-Resistance
Bottom-fixed plate pack for outstanding vibration resistance.
Parameter List
Swipe View
| Model | Series | Rated Voltage(V) | 20hr @1.75V/cell | RC(min) | CCA @-18°C(A) | Length(mm) | Width(mm) | Height(mm) | Weight(kg) | Cell Layout | Terminal | Hold Down | Handle |
| EFB-180L | 51 | 12 | 180 | 360 | 1000 | 510 | 222 | 217 | 47.4 | 4 | 1 | B0 | TS8 |
| EFB-180R | G51 | 12 | 180 | 360 | 1000 | 510 | 222 | 217 | 47.4 | 3 | 1 | B0 | TS8 |
| EFB-180R | G51 | 12 | 180 | 360 | 1100 | 513 | 222 | 216.5 | 47.7 | 3 | 1 | B0 | TS8 |
| EFB-220L | H52 | 12 | 220 | 456 | 1280 | 521 | 261 | 240.5 | 59.8 | 4 | 1 | B0 | TS8 |
| EFB-220R | H52 | 12 | 220 | 456 | 1280 | 521 | 261 | 240.5 | 59.8 | 3 | 1 | B0 | TS8 |
| EFB-225R | H52 | 12 | 225 | 468 | 1280 | 518 | 274 | 237.5 | 61 | 3 | 1 | B0 | TS8 |
