Forklift Tubular PzS Series

Traction lead-acid batteries serve as DC power sources for forklifts, tractors, carriers, underground mining locomotives, and other industrial equipment. They are widely used in airports, railway stations, ports, vegetable and fruit markets, and warehouses of industrial and mining enterprises. Meanwhile, vehicles powered by such DC power supplies are widely used in public transportation, sports venues, and entertainment facilities.

Applications:

Truck series
Stacker truck series
Forklift series
Tractor series
Counterweight forklift series

Request a Quote

Key Features

Tubular Positive Plate

Good corrosion resistance, long battery life.
Special Grid Alloy Formula

Special grid alloy formula is used to slow down grid corrosion. Reduce the waterloss rate, reduce the number of maintenance, achieve half-maintenance, improve the battery life.
Improved Capacity & Service Life

Improve the density of the active substance in the tube positive plate, prevent the softening and shedding of the active substance.
Special Electrolyte Formula

Prevent cathode passivation and dendrite short circuit.
Automatic water filling system (optional).

Parameter List

Swipe View

Model	Rated Voltage(V)	5hr @1.70V/cell	Length(mm)	Width(mm)	Height(mm)	Total Height(mm)	Dry Weight (kg)	Gross Weight (kg)
2PzS200	2	200	47	198	569	601	10.2	13
2PzS200C	2	200	47	198	569	601	9.8	12.6
3PzS210G	2	210	65	198	404	436	9.9	12.9
3PzS210	2	210	65	198	404	436	10.2	13.2
2PzS210	2	210	47	198	513	545	9.6	12.8
2PzS230	2	230	47	198	543	575	10.2	13.7
3PzS240G	2	240	65	198	469	501	10.8	14.2
3PzS240	2	240	65	198	469	501	11.4	14.8
2PzS250	2	250	47	198	574	606	10.9	14.4
3PzS270	2	270	65	198	469	501	12	15.8
4PzS280G	2	280	83	198	404	436	12.6	16.6
3PzS300C	2	300	65	198	569	601	13.7	17.9
4PzS320	2	320	83	198	404	436	13.3	17.8
3PzS345	2	345	65	198	543	575	14.3	19.6
4PzS360	2	360	83	198	469	501	15.3	20.5
3PzS375	2	375	65	198	574	606	15.2	20.5
5PzS400	2	400	101	198	404	436	16.2	21.8
4PzS400C	2	400	83	198	569	601	17.6	23.2
4PzS400	2	400	83	198	569	601	18.4	24
6PzS420G	2	420	119	198	404	436	18.1	24.1
3PzS420	2	420	65	198	688	720	18	24.4
4PzS440	2	440	83	198	536	568	18.9	25.4
3PzS450	2	450	65	198	720	752	18.8	25.3
4PzS460	2	460	83	198	543	575	18.4	25.4
6PzS480	2	480	119	198	404	436	19.1	25.9
4PzS480H	2	480	83	198	569	601	19.5	26.3
4PzS480	2	480	83	198	643	675	21	27.8
5PzS500C	2	500	101	198	569	601	21.4	28.5
5PzS500	2	500	101	198	569	601	22.4	29.5
4PzS500	2	500	83	198	643	675	22.1	28.9
4PzS560	2	560	83	198	688	720	23.2	31.8
5PzS575	2	575	101	198	543	575	22.5	31.3
6PzS600	2	600	119	198	569	601	25.3	33.8
5PzS600C	2	600	101	198	643	675	25.5	34
5PzS600H	2	600	101	198	569	601	23.8	32.3
4PzS600	2	600	83	198	720	752	24.3	32.8
9PzS630G	2	630	173	198	401	433	26.9	35.8
9PzS630	2	630	173	198	404	436	28	36.9
8PzS640	2	640	173	198	404	436	24.4	33.5
5PzS650	2	650	101	198	682	714	26.9	36.2
7PzS700C	2	700	137	198	569	601	29.2	39.1
5PzS700	2	700	101	198	688	720	28.4	39.1
8PzS720	2	720	155	198	469	501	28.9	39.1
6PzS720	2	720	119	198	569	601	28.1	38.4
5PzS750	2	750	101	198	720	752	29.8	40.4
7PzS840	2	840	137	198	569	601	32.5	44.4
8PzS920	2	920	155	198	543	575	35.4	50
8PzS1240	2	1240	155	198	720	752	46.2	63.7
10PzS1550	2	1550	191	198	720	752	57.1	79.1
