Motorcycle High-Performance Flooded LB Series

Thin plates with special formula & separators, improve the battery's cranking performance.

Applications:

ATV
Jet ski
Motorcycle
Snowmobile
Lawn & Garden

Request a Quote

Key Features

Broad Vehicle Compatibility

Compatible with mainstream motorcycle models.
Thin Plate Technology

Increased active material area for stronger and more reliable starting performance.
TTP Welding Technology

Lower internal resistance for enhanced power output and efficiency.
Flooded Design

Supplied with a dedicated acid pack for extended dry storage and easy activation.

Parameter List

Swipe View

Model	Rated Voltage(V)	10hr @1.75V/cell	CCA @-18°C(A)	Length(mm)	Width(mm)	Height(mm)	Length(in)	Width(in)	Height(in)	Weight(kg)	Terminal
LB2.5L-C	12	2.5	19	80	70	105	3 2/16	2 3/4	4 2/16	1.1	∕
LB4L-B	12	4	50	120	70	92	4 3/4	2 3/4	3 5/8	1.65	A
LB4L-B(J)	12	4	35	120	70	92	4 3/4	2 3/4	3 5/8	1.55	A
LB6.5L-B	12	6.5	55	138	73	107	5 7/16	2 7/8	4 3/16	2.36	B
LB6.5L-B(J)	12	6	50	138	73	107	5 7/16	2 7/8	4 3/16	2.15	B
LB7-A	12	8	80	135	75	133	5 5/16	2 15/16	5 4/16	2.86	B
LB7-A(J)	12	8	65	135	75	133	5 5/16	2 15/16	5 4/16	2.66	B
LB7L-B	12	8	80	135	75	133	5 5/16	2 15/16	5 4/16	2.86	B
LB7C-A	12	8	80	130	90	114	5 2/16	3 9/16	4 8/16	2.84	E
LB9-B	12	9	95	135	75	139	5 5/16	2 15/16	5 8/16	2.99	B
LB9-B(J)	12	9	70	135	75	139	5 5/16	2 15/16	5 8/16	2.81	B
LB9L-B	12	9	95	135	75	139	5 5/16	2 15/16	5 8/16	2.99	B
LB9L-B(J)	12	9	70	135	75	139	5 5/16	2 15/16	5 8/16	2.81	B
LB10L-A2	12	11	130	134	89	145	5 4/16	3 8/16	5 11/16	3.94	D
LB10L-A2(J)	12	11	100	134	89	145	5 4/16	3 8/16	5 11/16	3.67	D
LB10L-B	12	11	130	134	89	145	5 4/16	3 8/16	5 11/16	3.9	B
LB10L-B(J)	12	11	100	134	89	145	5 4/16	3 8/16	5 11/16	3.65	B
LB10L-B2	12	11	130	134	89	145	5 4/16	3 8/16	5 11/16	3.94	D
LB12A-A	12	12	150	134	81	160	5 4/16	3 3/16	6 5/16	4.18	B
LB12A-A(J)	12	12	120	134	81	160	5 4/16	3 3/16	6 5/16	3.9	B
LB12AL-A	12	12	150	134	81	160	5 4/16	3 3/16	6 5/16	4.18	B
LB12AL-A(J)	12	12	120	134	81	160	5 4/16	3 3/16	6 5/16	3.9	B
LB12AL-A1	12	12	150	134	81	160	5 4/16	3 3/16	6 5/16	4.18	A
LB12AL-A2	12	12	150	134	81	160	5 4/16	3 3/16	6 5/16	4.18	B
LB12AL-A2(J)	12	12	120	134	81	160	5 4/16	3 3/16	6 5/16	3.9	B
LB12C-A	12	12	150	134	81	175	5 4/16	3 3/16	6 7/8	4.2	A
LB14-A2	12	14	170	134	89	166	5 4/16	3 8/16	6 9/16	4.44	D
LB14-A2(J)	12	14	130	134	89	166	5 4/16	3 8/16	6 9/16	4.19	D
LB14-B2	12	14	170	134	89	166	5 4/16	3 8/16	6 9/16	4.44	D
LB14L-A2	12	14	170	134	89	166	5 4/16	3 8/16	6 9/16	4.44	D
LB14L-A2(J)	12	14	130	134	89	166	5 4/16	3 8/16	6 9/16	4.19	D
LB14L-B2	12	14	170	134	89	166	5 4/16	3 8/16	6 9/16	4.44	D
LB14A-A2	12	14	170	134	89	176	5 4/16	3 8/16	6 15/16	4.44	D
HLB16A-A	12	15	150	151	91	180	5 15/16	3 9/16	7 1/16	5.09	C
HLB16A-AB	12	15	150	151	91	180	5 15/16	3 9/16	7 1/16	5.09	C
LB16B-A	12	16	175	160	90	161	6 5/16	3 9/16	6 5/16	5.24	A
LB16B-A1	12	16	175	160	90	161	6 5/16	3 9/16	6 5/16	5.24	C
LB16AL-A2	12	16	175	207	71.5	164	8 2/16	2 13/16	6 7/16	5.64	F
LB18L-A	12	18	210	180	90	162	7 1/16	3 9/16	6 6/16	5.64	C
LB16-B	12	19	220	175	100	155	6 7/8	3 15/16	6 2/16	6.06	B
LB16L-B	12	19	220	175	100	155	6 7/8	3 15/16	6 2/16	6.06	B
LB16CL-B	12	19	220	175	100	175	6 7/8	3 15/16	6 7/8	6.13	A
L50-N18L-A	12	20	235	205	90	162	8 1/16	3 9/16	6 6/16	6.58	C
L50-N18L-A3	12	20	235	205	90	162	8 1/16	3 9/16	6 6/16	6.58	A
L60-N24L-A	12	28	280	184	124	170	7 4/16	4 7/8	6 11/16	7.96	G
L60-N24AL-B	12	28	280	184	124	170	7 4/16	4 7/8	6 11/16	7.96	G
L60-N30L-A	12	30	300	184	130	170	7 4/16	5 2/16	6 11/16	8.41	G
L60-N30L-A/HD(J)	12	30	280	184	130	170	7 4/16	5 2/16	6 11/16	7.98	G
L60-N30-A	12	30	300	184	130	170	7 4/16	5 2/16	6 11/16	8.41	G
L60-N30L-B	12	30	300	184	130	170	7 4/16	5 2/16	6 11/16	8.41	G
L60-N30L-B/HD(J)	12	30	280	184	130	170	7 4/16	5 2/16	6 11/16	7.98	G
LB30L-B	12	29	300	165	130	176	6 8/16	5 2/16	6 15/16	8.19	A
LB30CL-B	12	29	300	165	130	192	6 8/16	5 2/16	7 9/16	8.23	A
